XR Spatial Positioning Test System
BR-1000
XR spatial positioning test system with sub-millimeter test benchmark; complete test cases covering multiple application scenarios
Core Advantages
01High-Precision Test Bench
Equipped with high-precision shaft to accurately simulate the real movement of the head of the XR headset wearer; test cases can be freely edited
02 Automated Evaluation
A wireless bionic robot test workstation is used to achieve automated evaluation and ensure test consistency; positioning data alignment and calculation result output can be automated
03 Multi-Dimensional Test Items
It includes five dimensions: positioning accuracy, positioning scale, stability, positioning robustness, and initialization quality; it has more than 20 test scenarios, which are close to the actual usage scenarios of head-mounted display users.
Specifications
Positioning the Camera | |
Resolution, frame rate | 2.2MP、360fps–500+fps |
Positioning accuracy | +0.15mm |
Main specifications of the robot arm | |
Degrees of Freedom | 6-axis, 360° rotation |
load | 5kg |
Movement accuracy | 士0.03mm |
Mobile Platform Main Specifications | |
Running speed | 1.5m/s(max, adjustable) |
Positioning accuracy (running/docking) | ±1cm，±1° |
Navigation | Laser SLAM navigation; custom cruise; automatic homing; |
Full load endurance | About 8h |
Charging time | About 2h |
Charging method | Manual/Automatic |
Communication | Wi-Fi, GigE |
